Main Unit Parameters |
|
Scanning Model |
Electronic Linear Array, Electronic Convex Array
|
|
Cine-loop
|
≥500 frames |
Display Depth |
≥240mm; 16 levels are adjustable |
Display Mode |
B、B+B、B+M、B+M/M、M、4B
|
Focus Adjustment |
Focus Number, Focus Distance, Focus Position
|
|
Image Reversal
|
Up and down, Left and Right, Black and White |
Image Processing |
Image Smoothing/Sharpening, tissue harmonic, Gamma Correction,
Histogram, Pseudo-color
|
|
Real-time Depth
|
16 levels; Zoom |
Text |
Date, Clock, Name, Medical Record No., Gender, Age, Doctor, Hospital,
Full-screen Character Editing, Body mark and Position Indicator
|
Features
WED-2018 adopts multiple technologies such as micro-computer control and digital scan converter (DSC), digital beam-forming (DBF), real time dynamic aperture (RDA), real time dynamic receiving apodization, real time Dynamic receiving
focusing (DRF), Digital frequency Scan (DFS), frame correlation technologies and so onAll these technologies can endure
its image with clarity, stability and high resolution in the wide medical screen.
Combined power supply mode of AC adapter and built-in chargeable battery, 3 battery charging modes and the low power
consumption and advanced power management technology promise more lasting battery operation. The handle structure
and plastic injection model make whole units be small volume and light weight, so it can satisfy out door diagnosis.
